10 Inch Rack Mount 1.5U for the NETGEAR MS108UP / MS108EUP
A 1.5U tray that seats a NETGEAR MS108UP or MS108EUP in a 10 inch mini rack, printed to order in matte black PETG. The switch slides in from the front, through the window, until it touches the two rear stop posts, and sits about 11 mm proud of the faceplate. It rests on an open honeycomb floor and the rear of the tray is open for cables. No adhesive, no modification to the switch.
Designed From The Published Specification
- Fits: NETGEAR MS108UP and MS108EUP, 210 x 140 x 40 mm (W x D x H) per NETGEAR, inserted with the 8 RJ45 ports forward.
- Why 1.5U: a 40 mm switch plus the floor under it is taller than a 1U (44.45 mm) faceplate allows with clearance.
- Opening 212 x 43 mm over a flush floor: 1 mm of side clearance and 3 mm above the 40 mm body (leave NETGEAR's optional stick-on footpads off).
- Faceplate 248 mm wide on EIA-310 10 inch hole spacing; 1.5U (66.7 mm) tall.
Build
- Single piece.
- Open honeycomb floor and an open rear.
- Fits any 10 inch / 254 mm mini rack with standard square or round holes. The mounting slots take M6, M5, #10-32 or M4 rack screws.
- Part measures 248 x 137 x 66.7 mm. Matte black PETG.
Printed To Order
Each unit is printed fresh in our shop on calibrated printers and inspected before it ships. Lead time is typically 1-3 business days. Minor layer lines are normal for FDM 3D printing and part of the finish.
Mount only. Switch and power adapter not included. The rack and the device shown in the photos are not included; they appear for scale and fitment only.
Not an official NETGEAR product; NETGEAR is a trademark of its owner.
