10 Inch Rack Mount 1U for Zyxel GS1200-8
A 1U tray that seats the Zyxel GS1200-8 in a 10 inch mini rack, printed to order in matte black PETG. It slides in from the front, through the window, until it touches the two rear stop posts, and sits about 11 mm proud of the faceplate. No adhesive, no modification to the device.
Designed From The Published Specification
- Fits: Zyxel GS1200-8 8-port web managed switch, 155 x 85 x 26 mm per Zyxel.
- Not for the GS1900-8, GS1915-8 or XGS1210-12: those are 250 mm wide.
- Opening 157 x 31 mm over a flush floor: 1 mm of side clearance and 5 mm above the 26 mm body.
- Faceplate 248 mm wide on EIA-310 10 inch hole spacing; 1U (44.45 mm) tall.
Build
- Single piece.
- Vented rhythm-slot face and an open honeycomb floor.
- Fits any 10 inch / 254 mm mini rack with standard square or round holes. The mounting slots take M6, M5, #10-32 or M4 rack screws.
- Part measures 248 x 82 x 44.45 mm. Matte black PETG.
Printed To Order
Each unit is printed fresh in our shop on calibrated printers and inspected before it ships. Lead time is typically 1-3 business days. Minor layer lines are normal for FDM 3D printing and part of the finish.
Mount only. Switch and power adapter not included. The rack and the device shown in the photos are not included; they appear for scale and fitment only.
Not an official Zyxel product; Zyxel is a trademark of its owner.
