10 Inch Rack Mount 3U for the Raspberry Pi Touch Display 2 (7 inch)
A 3U front panel that holds the 7 inch Raspberry Pi Touch Display 2 in landscape in a 10 inch mini rack, printed to order in matte black PETG. The display slides down into the panel from the top, sits behind a window framed to its visible area, and is held by four M2.5 screws from behind into its own corner mounting holes.
Designed From The Published Specification
- Fits: Raspberry Pi Touch Display 2, 7 inch: 189.32 x 120.24 mm glass per Raspberry Pi's drawing, landscape either way up.
- Window 156.4 x 88.7 mm over the 155.4 x 87.7 mm visible area.
- Mounting: four holes on the display's 140 x 70.7 mm corner mounting pattern; the rear plates stand 0.3 mm behind its corner brackets.
- Screws: four M2.5 x 6 mm (not included).
- Faceplate 248 mm wide on EIA-310 10 inch hole spacing; 3U (133.35 mm) tall.
Build
- Single piece.
- Vented rhythm-slot face.
- Fits any 10 inch / 254 mm mini rack with standard square or round holes. The mounting slots take M6, M5, #10-32 or M4 rack screws.
- Part measures 248 x 18 x 133.35 mm. Matte black PETG.
Printed To Order
Each unit is printed fresh in our shop on calibrated printers and inspected before it ships. Lead time is typically 1-3 business days. Minor layer lines are normal for FDM 3D printing and part of the finish.
Mount only. Display, Raspberry Pi, cables and screws not included; the rack and display in the photos are shown for scale and fitment only.
Not an official Raspberry Pi product; Raspberry Pi is a trademark of Raspberry Pi Ltd.
