The Advantech PCI-1612A/9-BE is an industrial PCI communication card for serial multi-port communication in industrial PCs and automation systems. The PCI-1612A model has four independent RS-232/422/485 interfaces and enables data transfer rates of up to 921.6 kbit/s. The card uses the PCI bus and supports automatic plug-and-play resource allocation. Thanks to powerful UART communication controllers with FIFO buffers, stable data transmission is guaranteed with low CPU load. The scope of delivery shown includes the PCI card, a DB37 to 4x DB9 cable, driver CD and documentation. The device is suitable for industrial automation, SCADA systems, PLC applications, data acquisition and serial communication with multiple devices at the same time.

Model: PCI-1612A/9-BE

Series: PCI-1600

Item number: PCI-1612A

Device type: PCI communication card

Bus interface: PCI 2.1

Number of ports: 4

Interface Type: RS-232/422/485

Card connection: DB37 socket

Cable included: DB37 to 4 x DB9

Maximum transfer rate: 921.6 kbit/s

Supported baud rates: freely configurable

Communication controller: 16PCI954 UART

FIFO buffer: 128 bytes per port

Flow control: RTS/CTS, Xon/Xoff

Data bits: 5, 6, 7, 8

Stop bits: 1, 1.5, 2

Parity: None, Even, Odd

RS-485 support: automatic data flow control

I/O address assignment: PCI Plug & Play

Supported operating systems: Windows, Linux

Operating Humidity: 5-95% RH non-condensing

Operating temperature: 0°C to +65°C

Storage temperature: -25°C to +85°C

Dimensions: 185 x 100mm

Certifications: CE, FCC Class A, RoHS

Country of manufacture: Taiwan

Note for EU business customers:Our offers include German VAT (19%) as standard.If you are a company with a valid VAT ID number. If you would like to purchase from another EU country and want to use the reverse charge regulation, please contact us before purchasing. We will then adjust the offer to the net price (0% VAT) and issue you a corresponding invoice.The Advantech PCI-1612A/9-BE is an industrial PCI communication card for serial multi-port communication in industrial PCs and automation systems. The PCI-1612A model has four independent RS-232/422/485 interfaces and enables data transfer rates of up to 921.6 kbit/s. The card uses the PCI bus and supports automatic plug-and-play resource allocation. Thanks to powerful UART communication controllers with FIFO buffers, stable data transmission is guaranteed with low CPU load. The scope of delivery shown includes the PCI card, a DB37 to 4x DB9 cable, driver CD and documentation. The device is suitable for industrial automation, SCADA systems, PLC applications, data acquisition and serial communication with multiple devices at the same time. If you are a company with a valid VAT ID number. I
