General Information Manufacturer: Cisco Product ID: C3230-1WMIC-K9 Product Description: Cisco 3230 with one Wireless MIC Product Type: Wireless Integrated Services RouterMarketing Information

The Cisco 3230 Rugged ISR is a rugged router that uses Cisco IOS Software to provide access, mobility, and interoperability across multiple wired and wireless networks. The Cisco 3230 Rugged ISR has a flexible, compact form factor that is ruggedized to withstand harsh environments. It offers highly secure data, voice, and video communications in mobile and outdoor embedded networks. For mobile applications, standards-based Mobile IP delivers transparent roaming across multiple wireless networks capable of covering wide geographic areas. The components can also be placed in customized enclosures or existing outdoor infrastructure to connect proprietary network devices with an IP network.

Wireless Specifications Wireless LAN Standard: IEEE 802.11a/b/g ISM Band: Yes UNII Band: Yes ISM Maximum Frequency: 2.40 GHz UNII Maximum Frequency: 5 GHz Total Wireless Transmission Speed: 6.75 MB/sInterfaces/Ports Fast Ethernet Port: Yes Number of Network (RJ-45) Ports: 4 Management Port: YesNetwork & Communication Ethernet Technology: Fast EthernetManagement & Protocols Management:

• IEEE 802.1q VLAN
• IEEE 802.1p Security Features: Inspection Characteristics Height: 5.9" Width: 6.8" Depth: 8" Weight (Approximate): 14.20 lbMiscellaneous Package Contents:
  • 3230 Rugged Wireless Integrated Services Router
  • 1 x Wireless MIC (C3202WMIC-A49-K9)
  Additional Information:
  • Multiple WAN and LAN Connections
  • Optional rugged enclosure from Cisco for in-vehicle deployments
  • Cisco Unified CallManager Express (CUCME) support
  • Always-on wireless access for vehicle networks, with easy mobility through Mobile IP regardless of location or movement
