HPE Smart Array P441/4GB FBWC 12Gb 2-port external SAS controller - full-height PCIe RAID controller with two external mini-SAS ports, supplied with its 4GB flash-backed write cache module fitted. Removed from service, fully tested and working.
Identification read from the card's own labels:
- Spare part number: 749798-001
- Assembly number: 784484-001
- Serial number: S57CDQ1QS3
- Cache module assembly: 726815-002, marked 4GB
- Capacitor-pack cable spare number: 792836-001 (Molex)
- SAS address: 5001438042EAEDA0
- Interface: PCI Express 3.0 x8
- Ports: 2 external mini-SAS, 12Gb/s SAS and 6Gb/s SATA
What is included: the controller with its 4GB FBWC cache module and the capacitor-pack cable, all as shown in the photo, plus the full-height bracket fitted to the card.
What is not included: the capacitor pack / Smart Storage Battery itself, SAS cables, low-profile bracket, drivers, documentation, or any server.
Condition and defects: cosmetically clean with light handling marks. The external mini-SAS ports and the gold-finger edge connector are undamaged and the bracket is straight. Please review the photo - it is of the actual card you will receive.
Testing status: tested and working. The controller was installed in a server, detected by the host and initialised normally with the 4GB cache module recognised. It is sold in working order.
Shipping: ships from Fort Worth, Texas, in an anti-static bag with protective padding.
