LMR-100 (N type Male – N type Male) 20cm Cable in WHITE
The Ultra Low Loss LMR-100 Window Pass Through Cable is 50% lower loss than the original window pass cable.
McGill Microwave Systems have been trialling an innovative, ultra low loss solution to solve the problem of how to connect your internal Helium Hotspot box to your outdoor Antenna cable – avoiding any need to drill holes through window frames or walls to pass the Antenna cable through…and all with minimal RF signal loss.
Developed originally for many high frequency uses in the commercial and military world; the unique, thin, ultra low loss Low Loss LMR-100 cable is can pass through most existing window frames, patio doors and under standard doors – without the need for any drilling or DIY.
Simply open your window or patio door, place the flat cable in the frame and carefully close the window or patio door again – job done!
Ideal when installing Hotspots in other people’s property – nobody likes having holes drilled through their external walls to the outside elements.
Specifications of LMR-100 (N type male – N type male) 20cm Cable
- McGill Microwave Part No: LPV100NMNM0.2M.
- Cable Assembly Length; 200 mm
- Cable Diameter: 2.54mm
- Connector Types; N type male and N type male
- Low Insertion /Signal Loss; 0.4 dB’s max over the Helium UK/EU/USA frequency bands.
- Fully weatherproof cable assembly
Helium miner and required cable connector
Helium miner type
Required connector type to meet miner LoRaWAN interface
Bobcat Bobcat 300
RP SMA MALE
RP SMA MALE
NEBRA Indoor
RP SMA MALE
NEBRA Outdoor
N MALE
SyncroB.it
SMA MALE
LongAP ONE
SMA MALE
LongAP Pro
N MALE
LongAP Light
SMA MALE
Original Helium (First 700 Hotspots)
SMA MALE
Sensecap M1
RP SMA MALE
Clodpi Pro hotspot
SMA MALE
SMA MALE
FXTec Linxdot
RP SMA MALE
Heltec indoor hotspot
RP SMA MALE
Kerlink
RP SMA MALE
Dragino
SMA MALE
*The table above indicates which type of connector your cable must have to allow it to connect to the relevant Helium miner*
