1. Control Board: Upgrade version with more protection circuits and function interfaces. Added independent DC5V for Pi and reserved for Robin WIFl interface for for RRF firmware.
2. 8 Axes Control Board: Supports for Marlin2.0.x, and for Klipper hardware, compatible with for Mini12864 LCD screen. Enables U disk printing and DFU mode setting through Booto button.
3. Support: For large 3D printers with 8 stepper drivers and 9 motor interfaces. Compatible with various motor drivers for flexible upgrades. For motherboards can be used on for Ender 3, for Ender 3 V2 and for Ender 3 pro, please update the firmware on for Github first.
4. Working Parameters: DC12‑24V Input. Integrated SPI communication micro storage card and reserved SPI signal interface. 2 MP1584EN outputs DC12V (for fan) and DC5V.
5. For Mini 12864 V3.0 Display: Storage card slot display with RGB backlit. Supports various firmwares and onboard encoder for parameter adjustment and file selection printing.
Specification:
Item Type: Motherboard
Material: PCB
Input Voltage: DC12-24V, <30A
Output Voltage: DC12V, DC5V, DC3.3V
3D Touch: Support
Hardware: Support for 2.0.X, for Klipper
MCU: STM32F407VET6, 168MHz, 512KB Flash, 192KB RAM
External Stepper Signal: Yes
MOS Circuit Protection: Resistor and for Schottky Diode Protection
Limit Circuit Protection: Resistor and for Schottky Diode Protection
Temperature Circuit Protection: Resistor and for Schottky Diode Protection
Motor Back EMF: Absorbed by phase sequence resistance
PA13 Pin: Used for MT DET
PC5 Pin: Used for Neo px
for E4 EN Signal: Same as E0 EN=PB6
For Robin Wifi Interface: Yes
for MAXIMUM31865 Interface: Yes, same as E4 axes signal
for Raspberry Power: Independent DC5V 3A power supply
Limit Switch Power: Only Z and can choose 5V or VIN, other limit switches are 5V
for Mini12864 V3.0 LCD Graphic Smart Display
Mode: for Mini 12864 V3
Material: PCB
Logic Level: Support 3.3V, 5V logic input
Backlit Mode: for Neo pxRGB adjustable backlit
Backlit Adjustment: Light slightly preset (for )
Firmware: for 2.0, for Klipper
Compatible Mainboards: for Robin Nano V2,for SgenlV1, V2, for Genl, for Robin E3
Features:
1. Use the built in storage card slot.
2. Compatible with both 3.3V and 5V logic signals.
3. Support for Gcode backlit settings, e.g. for M150 for R100 for G100 for U100.
4. Compatible with for Robin Nano V2,for Sgen IV1, for Sgen V2, for GenI, for Robin E3.
5. for MINI 12864 V3 Smart Display has RGB backlit, supports changing backlit color online via LCD.
6. Support color changes in different states during printing.
7. Communicate with host microcontroller via for SPI.
8. Support for Klipper 2.0 firmware.
