Product Specifications

• Connector 1: LC UPC

• Connector 2: LC UPC

• Fiber Mode: Singlemode 9/125 μm

• Fiber Type: Duplex

• Cable Jacket: Single Armored

• Cable Color: Blue

• Construction Material: Stainless steel tube + PVC outer jacket

• Insertion Loss: ≤0.3 dB

• Return Loss: ≥50 dB

• Operating Temperature: -40°C to +85°C

Key Features

• Low insertion loss & high return loss for stable, long-distance transmission

• Armored stainless-steel protection—resistant to crushing, bending, and rodent damage

• Light-tight, rugged construction ideal for harsh environments

• Highly flexible while maintaining durability

• RoHS, REACH & SVHC compliant

• Easy to install and engineered for tough field conditions

Applications

Perfect for professional fiber deployments such as:

• CATV / CCTV / Video transmission

• Passive optical network (PON)

• FTTX / FTTH installations

• SONET / WDM systems

• Data centers & telecom

• Industrial and military-grade use cases

Why Choose Armored Fiber Patch Cables?

Armored fiber cables offer premium protection compared to standard patch cords.
They withstand pressure, crushing, rodents, and improper twisting—making them ideal for outdoor, underground conduit, or harsh-environment installations.
They maintain excellent optical performance and provide a long service life with minimal maintenance.
