• Unique FeatureASRock USB 3.1 Gen2
  - ASRock USB 3.1 Gen2 Type-A Port (10 Gb/s)
  - ASRock USB 3.1 Gen2 Type-C Port (10 Gb/s)
  ASRock Super Alloy
  - Premium 60A Power Choke
  - Dr. MOS
  - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
  - Matte Black PCB
  - High Density Glass Fabric PCB
  Intel®Dual Band Wireless-AC 8265 (AC Wave 2 + BLE BT4.2)
  ASRock Steel Slots
  ASRock Ultra M.2(PCIe Gen3 x4 & SATA3)
  ASRock Full Spike Protection(for all USB, Audio, LAN Ports)
  ASRock Live Update & APP Shop
• CPU- Supports Intel®Core™ X-Series Processor (79xx, 78xx Series) for the LGA 2066 Socket*
  - Digi Power design
  - 7 Power Phase design
  - Supports Intel®Turbo Boost Max Technology 3.0
  - Supports ASRock Hyper BCLK Engine III

  *Supports 28 and 44 PCIe lane processors (6-core and above) only. 16 PCIe lane processors (4-core) are not supported.
• Chipset- Intel®X299
• Memory- Quad Channel DDR4 Memory Technology
  - 4 x DDR4 SO-DIMM Slots
  - Supports DDR4 4000+(OC)*/ 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3200(OC) / 2933(OC) / 2800(OC) / 2666 / 2400 / 2133 non-ECC, un-buffered memory
  - Max. capacity of system memory: 128GB**
  - Supports Intel®Extreme Memory Profile (XMP) 2.0

  *Intel®X299 does not support 1Rx16 memory modules.
  The maximum memory frequency supported may vary by processor type.

  **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows®32-bit OS. For Windows®64-bit OS with 64-bit CPU, there is no such limitation.
• BIOS- 128Mb AMI UEFI Legal BIOS with multilingual GUI support
  - ACPI 6.1 Compliant wake up events
  - SMBIOS 3.0 Support
  - CPU, DRAM, PCH 1.0V, VCCIO, VCCSA, Voltage Multi-adjustment
• Graphics- n/a
• Audio- 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
  - Premium Blu-ray Audio support
  - Supports Surge Protection
  - Supports Purity Sound™ 4
  - Nichicon Fine Gold Series Audio Caps
  - 120dB SNR DAC with Differential Amplifier
  - NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets)
  - Pure Power-In
  - Direct Drive Technology
  - Impedance Sensing on Rear Out port
  - Gold Audio Jacks
  - 15μ Gold Audio Connector
  - Supports DTS Connect
• LAN- Gigabit LAN 10/100/1000 Mb/s
  - 1 x Giga PHY Intel®I219V, 1 x GigaLAN Intel®I211AT
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection
  - Supports Dual LAN with Teaming*
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE

  *Teaming is supported on Windows®10 RS2, RS3 and RS4.
• Wireless LAN- Intel®Dual Band Wireless-AC 8265
  - Supports IEEE 802.11a/b/g/n/ac
  - Supports Dual-Band (2.4/5 GHz with 80Mhz bandwidth and MU-MIMO)
  - Supports high speed wireless connections up to 867Mbps
  - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
  - Supports Bluetooth 4.2 / 3.0 + High speed class II
• Slots- 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*
  - 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac module (on the rear I/O)
  - 15μ Gold Contact in VGA PCIe Slot (PCIE1)

  *Supports PCIe riser cards to extend one x16 slot to two x8 slots
• Storage- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel®Rapid Storage Technology 15 and Intel®Smart Response Technology), NCQ, AHCI and Hot Plug
  - 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)*
  - 2 x Ultra M.2 Sockets (M2_2 and M2_3), support M Key type 2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s)*

  *Supports Intel®Optane™ Technology M10 Series (M2_1)
  Supports NVMe SSD as boot disks
  Supports Virtual RAID On CPU (M2_2 and M2_3)
• Connector- 1 x Virtual RAID On CPU Header
  - 1 x TPM Header
  - 1 x Power LED and Speaker Header
  - 1 x RGB LED Header*
  - 1 x CPU Fan Connector (4-pin)**
  - 1 x CPU Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
  - 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)****
  - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
  - 1 x Front Panel Audio Connector (15μ Gold Audio Connector)
  - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
  - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)
  - 1 x Rear Button Switch (A: Clear CMOS Button; B: Power Button)

  *Supports in total up to 12V/3A, 36W LED Strip

  **The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.

  ***The CPU Optional/Water Pump Fan supports the water cooler fan of maximum 1.5A (18W) fan power.

  ****CPU_OPT/W_PUMP and CHA_FAN1 can auto detect if 3-pin or 4-pin fan is in use.
• Rear Panel I/O- 2 x Antenna Ports
  - 1 x Optical SPDIF Out Port
  - 1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (ASMedia ASM3142) (Supports ESD Protection)
  - 1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (ASMedia ASM3142) (Supports ESD Protection)
  - 4 x USB 3.1 Gen1 Ports (ASMedia ASM1074 Hub) (Supports ESD Protection)*
  - 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED)
  - 1 x Clear CMOS Button / Power Button
  - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)

  *If you remove X299E-ITX REAR card, USB 3.1 Gen1 ports and RJ-45 LAN Ports will not work.
• Software and UEFISoftware
  - ASRock A-Tuning
  - ASRock RGB LED
  - ASRock XFast LAN
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock My Favorites in UEFI
  - ASRock Instant Flash
  - ASRock Internet Flash
  - ASRock Crashless BIOS
  - ASRock UEFI System Browser
  - ASRock UEFI Tech Service
  - ASRock Easy RAID Installer

  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• Support CD- Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories- Quick Installation Guide, Support CD, I/O Shield
  - 4 x SATA Data Cables
  - 1 x ASRock WiFi 2.4/5 GHz Antenna
  - 3 x Screws for Ultra M.2 Sockets
• Hardware Monitor- Temperature Sensing: CPU, CPU Optional/Water Pump, Chassis Fans
  - Fan Tachometer: CPU, CPU Optional/Water Pump, Chassis Fans
  - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU Optional/Water Pump, Chassis Fans
  - Fan Multi-Speed Control: CPU, CPU Optional/Water Pump, Chassis Fans
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V, VCCIO, VCCSA
• Form Factor- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
  - 10 Layer PCB
• OS- Microsoft®Windows®10 64-bit
• Certifications- FCC, CE, WHQL
