Compatible CB15U-K30-5 Blade for Graphtec FC8600 FC9000 FC4500 FC2250 FCX2000 FCX4000 🛠️ CUTTING BLADE | CB15U-K30-5 | JAPAN IMPORTED | 30°∠ 1.5mmφ | GRAPHTEC FC SERIES
Product Name : Compatible Cutting Blade
Compatible Model : CB15U-K30-5
Origin & Quality : Japan Imported, High-quality Ultra-hard Steel
Core Specification : 1.5mm Diameter, 30° Blade Angle
Product Function : Replace Original Blade for Graphtec Cutting Plotter
Applicable Brand : Graphtec (FC Series Cutting Plotter)
Japan Imported CB15U-K30-5 Compatible Blade for Graphtec FC8600 FC9000 FC4500 FC2250 FCX2000 FCX4000
This is a Japan imported high-quality compatible cutting blade for Graphtec FC series cutting plotters, perfectly compatible with the original CB15U-K30-5 blade. Made of premium ultra-hard steel with professional precision grinding technology, it features super high hardness, sharp cutting edge, wear resistance and long service life, and is an ideal replacement for the original Graphtec blade. With the standard specification of 1.5mm blade diameter and 30° blade angle, it is specially designed for cutting hard/thick sheets (thickness about 0.25-0.5mm) and small text patterns on marking film (max thickness about 0.25mm). The blade has precise size, perfect matching with Graphtec blade holders, smooth cutting without burrs, and can maintain high cutting precision even for fine small text patterns, fully meeting the industrial cutting needs of different thick and hard materials.
📋 Core Specifications & Material Features
Compatible Blade Model : CB15U-K30-5
Origin : Japan Imported
Material : High-quality Ultra-hard Steel
Blade Diameter : 1.5mm
Blade Angle : 30°
Cutting Edge Process : Precision Grinding, Ultra-sharp
Core Performance : Super Hardness, High Wear Resistance, Burr-free Cutting, Long Service Life
Matching : Perfect Fit with Graphtec Original Blade Holder
Product Attribute : Direct Replacement for Original Blade
🎯 Exact Applicable Cutting Scenarios
30° Angle & Ultra-hard Steel - For Hard/Thick Materials & Fine Patterns
- Cutting various hard or thick sheets with a thickness of about 0.25-0.5mm
- Carving small text patterns on marking film (max thickness about 0.25mm)
- Industrial cutting of high-hardness film, plastic sheet and thick adhesive material
- Fine cutting of small character patterns requiring high precision and no burrs
🔌 Exact Compatible Graphtec Models
- FC8600
- FC9000
- FC4500
- FC2250
- FCX2000
- FCX4000
📦 Package Contents
✔ Multiple PCS x Japan Imported CB15U-K30-5 Compatible Cutting Blade (Ultra-hard Steel)
🔧 Installation & Usage Guide & Key Warnings
⚠️ Power off before installation! Avoid touching the sharp blade directly!
- Completely power off the Graphtec cutting plotter and unplug the power cord to ensure safe operation.
- Remove the blade holder from the equipment's pen carriage, use the matching disassembly tool to take out the old blade gently.
- Take out the new CB15U-K30-5 compatible blade, hold the non-cutting edge part, and do not touch the sharp cutting edge directly to avoid injury.
- Insert the new blade into the blade holder along the slot, adjust the exposed length of the blade according to the material thickness (0.25-0.5mm for thick/hard materials), and fix it tightly.
- Reinstall the blade holder to the pen carriage, ensure it is fixed firmly without loosening.
- Put the test material into the equipment, set the corresponding cutting parameters, and perform a test cutting to verify the cutting effect is smooth without burrs.
Tip: Replace the blade in time when the cutting edge is blunt or worn; store the unused blade in a sealed box to avoid rust and damage; adjust the blade exposed length reasonably according to different material thicknesses.
🏢 Purchase Information
- Retail : Multiple PCS pack available for direct purchase, fast delivery for immediate replacement and use.
- Bulk : Volume discounts for orders over 100PCS, the larger the quantity, the more favorable the unit price, support long-term stable supply.
- Packaging : Sealed anti-rust packaging, protect the blade from rust, scratch and edge damage during transportation.
- Shipping : Global fast shipping with professional logistics, ensure the blade's sharpness and hardness are intact on arrival.
- Pre-sales Service : Free model & material matching service, confirm the blade fit for your cutting material and Graphtec equipment.
- Combination : Extra discount when purchased with other Graphtec cutting accessories (blade holder, pressure roller, cutting mat).
