Interface Ethernet
• 2 10/100/1000 Mbps WAN Ports
• 4 10/100/1000 Mbps LAN Ports

Wireless
• 802.11a/b/g/n (Dual Band)
• 3 Detectable 2dBi Omni-Directional Antennas

USB
2 USB 2.0

Console
RJ-45

System Performance8
• Firewall Throughput7: 130 Mbps
• VPN Throughput9: 70 Mbps
• Concurrent Sessions: 60,000
• New Sessions (per second): 600
• Firewall Policies: 600

Networking
• DHCP Server/Client
• DHCP Relay
• IEEE802.1q VLAN
• VLAN (Port-Based)
• IP Multicast IGMP Proxy
• IPv6
• Route Failover
• 3G Redundancy
• Outbound Load Balancing

Wireless
• Multiple Service Set Identifier (SSID)
• Service Set Identifier (SSID) to VLAN Mapping
• Wireless Security:
Wired Equivalent Privacy (WEP)
Wi-Fi Protect Setup (WPS)
Wi-Fi Protected Access
Personal (WPA-PSK)
Wi-Fi Protected Access
Enterprise (WPA-EAP)
Wi-Fi Protected Access version 2 – Personal (WPA-PSK)
Wi-Fi Protected Access version 2 – Enterprise (WPA-EAP)

Virtual Private Network (VPN)
• VPN Tunnels: 70
• Encryption Methods: DES, 3DES, AES, Twofish, Blowfish, CAST-128, NULL
• IPSec/PPTP/L2TP Server
• IPSec NAT Traversal
• Dead Peer Detection
• IP Encapsulating Security Payload (ESP)
• IP Authentication Header (AH)
• VPN Tunnel Keep Alive
• Hub and Spoke

SSL Virtual Private Network (SSL VPN)
• SSL VPN Tunnel: 20
• SSL Encryption Methods: DES, 3DES, AES
• SSL Message Integrity: MD5, SHA1

Bandwidth Management
• Max. Bandwidth Control
• Priority Bandwidth Control
Port-Based QoS
3 Classes

System Management
• Web-based User Interface: HTTP, HTTPS
• Command Line
• SNMP v1, v2c, v3
