CPU Socket 775
CPU Support Intel® Quad Core Q9550, Q9450, Q9300, Q6700 & Q6600, Core 2 Extreme X6800, Core 2 Duo E6850, Pentium® Dual-Core E2180, Pentium® D 960, Pentium® 4 Extreme Edition , Celeron® D 365 & Socket 775 Dual-Core Xeon® 3000 Sequence
Solution 1U
Overall Dimension 82.6 x 81.0 x 28.5 mm
Weight 340 g
Material Copper Heatsink
Fan Dimension 80 x 80 x 15 mm
Speed At Duty Cycle 20%: 1000 RPM
At Duty Cycle 50%: 2500 RPM
At Duty Cycle 100%: 5000 RPM
Bearing 2 Ball Bearing
Rated Voltage 12
Power At Duty Cycle 20%: 0.36 W
At Duty Cycle 50%: 0.96 W
At Duty Cycle 100%: 7.56 W
Air Flow At Duty Cycle 20%: 2.508 CFM
At Duty Cycle 50%: 7.214 CFM
At Duty Cycle 100%: 15.0 CFM
Noise Level At Duty Cycle 20%: 20.5 dBA
At Duty Cycle 50%: 35.6 dBA
At Duty Cycle 100%: 49.8 dBA
Air Pressure At Duty Cycle 20%: 0.032 inch-H2O
At Duty Cycle 50%: 0.338 inch-H2O
At Duty Cycle 100%: 1.424 inch-H2O
Lead Wire Pin Out Pin1-Black (-)
Pin2-Yellow (+)
Pin3-Green (Techometer/Signal output)
Pin4-Blue (PWM)
Note 1. Support power up to 130Watts refer to system arrangement
2. Orientations switchable without board components interference
3. Slim sized Backplate to avoid solder joint impact from all system boards
4. RoHS Compliance
