Item description
Gigabyte GA-AB350M-GAMING 3 DDR4 DIMM AMD B350 Socket AM4 Motherboard Micro ATX
Supports AMD Ryzen processors
Supports AMD 7th Generation A-Series/Athlon™ B350
RAM
4xDDR4 DIMM slots, support up to 64 GB
Supports dual-channel memory technology
Support DDR4 3200(O.C.)/2933(O.C.)/2667*/2400/2133 MHz
* Support for DDR4 2667 MHz or above will depend on the CPU.
Support ECC Un-buffered DIMM 1Rx8/2Rx8 memory (non-ECC mode operation)
Support non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory
Supports Extreme Memory Profile (XMP) memory
Display function
Built-in processor with display capability:
1xVGA interface, can support up to 1920x1200@60 Hz resolution
1xDVI-D interface, can support up to 1920x1200@60 Hz resolution
* This DVI-D interface does not support the function of converting to VGA.
1xHDMI interface, can support up to 4096x2160@24 Hz resolution
*Support HDMI version 1.4
* Supports up to three screen displays at the same time
Supports maximum shared display memory * 2 GB
* Whether this specification is supported depends on the CPU.
Sound effect
Built-in Realtek® ALC887 chip
Support High Definition Audio
Support 2/4/5.1/7.1 channel
* To enable 7.1-channel audio output, you must use the audio output jack on the front panel of the HD (High Definition) audio module, and select the multi-channel audio function through the audio software.
Support S/PDIF output
The internet
Built-in Realtek® GbE network chip (10/100/1000 Mbit)
Expansion slot
1xPCI Express x16 slot, supports x16 running specification (PCIEX16)
* To maximize the performance of the graphics card, be sure to install a *PCIEX16 slot when installing a graphics card.
* Whether this specification is supported depends on the CPU.
(PCIEX16 slot supports PCI Express 3.0)
1xPCI Express x16 slot, supports x4 running specification (PCIEX4)
1xPCI Express x1 slot
(PCIEX4 and all PCI Express x1 slots support PCI Express 2.0)
Storage device interface
1xM.2 socket (support Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD)
* Whether this specification is supported depends on the CPU
6xSATA 3.0 interface
Supports RAID 0, RAID 1 and RAID 10 in Chipset:
2xUSB 3.1 Gen 2 Type-A ports (red) on the rear panel
2xUSB 3.1 Gen 1 ports, which need to be connected from the USB socket on the motherboard via a flat cable
6xUSB 2.0 ports (2 on the rear panel, 4 need to be connected from the USB socket on the motherboard via a cable)
Built into the processor:
4xUSB 3.1 Gen 1 ports on the rear panel
Internal socket
1x24PIN motherboard power socket
1x8PIN CPU power socket
1xM.2 Socket 3 socket
6xSATA 3.0 interface
1xCPU fan socket
2x System Fan Sockets
1x front control panel socket
1x front audio jack
1xUSB 3.1 Gen 1 socket
1x onboard COM socket
1x Security Encryption Module (TPM) socket
2xUSB 2.0 sockets
1x onboard LPT socket
1x Clear CMOS data jumper
Rear panel unit connection socket
1xPS/2 keyboard/mouse interface
1xVGA interface
1xDVI-D interface
1xHDMI interface
4xUSB 3.1 Gen 1 ports
2xUSB 3.1 Gen 2 Type-A ports (red)
2xUSB 2.0 ports
1xRJ-45 network cable interface
3x audio interface (audio in, audio out, microphone)
I/O Controller
Built-in iTE® I/O controller chip
BIOS
2 x 128Mbit flash
Use an authorized AMI UEFI BIOS
DualBIOS™ support
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
operating system
Support Windows 10 64-bit
Support Windows 7 64-bit
*For Windows 7 64-bit system, AMD Summit Ridge & Bristol Ridge CPU is required
Form Factor
Micro ATX ; 24.4cm x 24.4cm
1 x motherboard.
2 x SATA II cables.
1 x I/O shield.
