Gigabyte MZ73-LM1 AMD EPYC™ 9004 DP Server Board Gen5 server E-ATX MB 9654 400w

304.8W x 335.2D mm

AMD EPYC™ 9004 series processors with AMD 3D V-Cache™ Technology
Dual processor, 5nm technology
Up to 128-core, 256 threads per processor
cTDP up to 400W

Socket SP5

DDR5 memory supported only
12-Channel memory architecture per processor
RDIMM modules up to 128GB supported
3DS RDIMM modules up to 256GB supported
Memory speed: Up to 4800 MHz

NCSI function supported1 x 10/100/1000 management LAN

2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM

2 x SlimSAS 8i with 4 x Gen4 NVMe or 16 x SATA ports, from CPU_1

Slot_3: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_0
Slot_2: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1
Slot_1: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_11 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU_0
- Supports 2280/22110 cards2 x SlimSAS 8i with 4 x Gen4 NVMe or 16 x SATA ports, from CPU_1

2 x 8-pin ATX 12V power connectors
2 x 6-pin ATX 12V power connectors
2 x SlimSAS 8i connectors
1 x M.2 slot
2 x CPU fan headers
4 x System fan headers
1 x USB 3.2 Gen1 header
1 x TPM header
1 x Front panel header
1 x HDD backplane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
1 x Buzzer

1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED

Optional TPM2.0 kit:CTM010

GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

2 x 8-pin ATX 12V power connectors
2 x 6-pin ATX 12V power connectors

Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

1 x I/O shield
1 x Quick start guide
1 x SlimSAS 4i to 4 x SATA 6Gb/s cable
Single Box dimensions: 409 x 355 x 78 mm
Carton dimensions: 729 x 415 x 432 mm
Quantity: 10 x single boxes in one carton

Bulk: 9MZ73LM1NR-000-10*
Part Numbers:
- I/O shield: 12AIO-MZ73L0-00R
- CPU cooler: 25ST0-0Z6022-C1R(optional)
- SlimSAS 4i to 4 x SATA 6Gb/s cable: 25CFM-600800-A4R

Without batteries, they will be removed and tested before shipment.(Batteries are prohibited items.)
