Tripp Lite SmartPro 3000VA RM 2U SMART3000RM2U
Light paint scuffs on one edge. Plastic front is coming off. Comes with all accessories - all sealed.
OVERVIEWUPC Code037332096685UPS TypeLine-InteractiveINPUTInput PhaseSingle-PhaseRated input current (Maximum Load)24A (120V)Nominal Input Voltage(s) Supported120V ACNominal Input Voltage Description80V-151V; adjustable to 70-153VUPS Input Connection TypeL5-30PUPS Input Cord Length (ft.)10Recommended Electrical Service30A 120VMaximum Input Amps24OUTPUTOutput Capacity (VA)3000Output Capacity (kVA)3Output Capacity (Watts)3000Output Capacity (kW)3Power Factor1Nominal Voltage Details120v nominal output in battery modeFrequency Compatibility50 / 60 HzOutput Voltage Regulation (Line Mode)120V (-13%, +15%)Output Voltage Regulation (Battery Mode)-10%, +6%Load Management ReceptaclesTwo switchable two-outlet load banksOutput Circuit BreakersThree 20A output breakers protect 2x 5-20R outlets eachOutput AC Waveform (AC Mode)Pure Sine waveOutput (Watts)3000Output AC Waveform (Battery Mode)Pure Sine waveNominal Output Voltage(s) Supported100V; 110V; 120V; 125VOutput Receptacles(6) 5-20R; (1) L5-30RIndividually Controllable Load BanksYesBATTERYBattery TypeValve Regulated Lead Acid (VRLA)Runtime Full Load (min.)3 min. (3000W)Runtime Half Load (min.)9 min. (1500W)DC System Voltage (VDC)72Battery Recharge Rate (Included Batteries)Less than 5 hours from 10 to 90% (typical, full load discharge)Battery AccessFront panel battery access doorInternal UPS Replacement Battery CartridgePre-May 2023: RBC94-2U Post-May 2023: 744-A3122Battery Replacement DescriptionHot-swappable, user replaceable batteriesVOLTAGE REGULATIONVoltage Regulation DescriptionAutomatic voltage regulation (AVR) maintains line power operation with an input voltage range of 81 to 150V (Normal mode) adjustable to 70-153V (Extended mode)Overvoltage CorrectionReduces incoming voltage between 132-151V by 13% (Normal Mode); 138-152V (Extended mode)Undervoltage CorrectionBoost incoming voltages between 81-102V by 15% (Normal Mode); 71-92V by 15% (Extended Mode)USER INTERFACE, ALERTS & CONTROLSFront Panel LCD DisplayFront panel LCD information and configuration screen offers detailed UPS and site power status and operating data, plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual for detailed LCD configuration and monitoring options)Switches5 pushbutton switches control OFF / ON power status, ENTER, UP, and DOWN selection and ESC control functionsAlarm Cancel OperationPress the ESC (Escape) button on the front panel display to silence the alarm. Check the alarm condition and perform the applicable action to resolve the condition. If the alarm status changes, the alarm beeps again, overriding the previous alarm silencingAudible AlarmAudible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditionsLED IndicatorsUPS Mode On (Solid Green); Battery Mode (Solid Orange)/ Battery Below Warning Level (Flashing Orange); Fault/Alarm (Solid Red).SURGE / NOISE SUPPRESSIONEMI / RFI AC Noise SuppressionYesAC Suppression Joule Rating380AC Suppression Response TimeInstantaneousPHYSICALPrimary Form FactorRackmount; TowerRack Height2UCooling MethodFanInstallation Form Factors Supported with Included Accessories4 post 19 inch rackmount; TowerInstallation Form Factors Supported with Optional Accessories4 post rackmount short-depth (4POSTRAILKITWM)Minimum Required Rack Depth (inches)27Optional Mounting Accessory NotesOptional 4POSTRAILKITWM enables installation in 4-post short-depth racks from 14.5 to 23.5 inches (368 to 597mm)Primary UPS Depth (mm)602Primary UPS Height (mm)86Primary UPS Width (mm)437Shipping Dimensions (hwd / in.)9.44 x 22.83 x 30.86Shipping Weight (lbs.)87.74UPS Housing MaterialSteelUPS Power Module Dimensions (hwd, in.)3.4 x 17.2 x 23.7UPS Power Module Weight (kg)33.79UPS Power Module Weight (lbs.)74.5Unit Dimensions (hwd / in.)3.400 x 17.200 x 23.700Unit Weight (lbs.)74.5Mounting DetailsRack-mounting hardware Tower support standsENVIRONMENTALOperating Temperature Range32° to 104°F (0° to 40°C)Storage Temperature Range5° to 122°F (-15° to 50°C)Relative Humidity20 to 90%, non-condensingAC Mode BTU / Hr. (Full Load)173AC Mode Efficiency Rating (100% Load)0.98Battery Mode Heat Dissipation (BTU/Hr) @ Full Load944Operating Elevation0-10000 ft. (0-3000 m)Storage Elevation (ft.)0-32,808Audible Noise50 dBA maximum, front side 1mCOMMUNICATIONSNetwork Management CardsWEBCARDLXENetwork Monitoring Port DescriptionNetwork Card Optional. Not compatible with WEBCARDLX.PowerAlert SoftwareFor local monitoring via the UPS’s built-in communication ports, download PowerAlert Office software at CableUSB and DB9 cabling includedNetwork UPS Tools (NUT) CompatibilityNUT compatible. See a full list of NUT compatible Tripp Lite UPS systems at Management Card DescriptionNetwork management card optionalCommunications InterfaceContact closure; DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface; USB (HID enabled)LINE / BATTERY TRANSFERTransfer Time1-4ms for normal modeLow Voltage Transfer to Battery Power (Setpoint)80High Voltage Transfer to Battery Power (Setpoint)151FEATURES & SPECIFICATIONSCold Start (Startup in Battery Mode During a Power Failure)Cold-start operation supportedHigh Availability UPS FeaturesAutomatic Voltage Regulation (AVR); Hot swappable batteries; Remote management; Sine wave output; Surge/noise protectionGreen Energy-Saving FeaturesGreater than 95% efficiency - GREEN UPS; Individually controllable load banksGrounding DetailsRear panel grounding lugAPPLICATIONSUPS ApplicationsHigh-End Desktop/Small Network; Large NetworkSTANDARDS & COMPLIANCEProduct CertificationsCAN/CSA-C22.2 No. 107.3 (Canada); ICES (Canada); NOM (Mexico); UL 1778Product ComplianceENERGY STAR Qualified; FCC Part 15 Class A (USA); RoHS
