Intel SRCSAS144E 8 Port Serial SATA/SAS RAID Controller

New Retail Box With Accessories

Includes: Cable, Driver Software And Additional Low Profile Bracket

Product Specifications:

The Intel® RAID Controller SRCSAS144E supports both serial-attached SCSI (SAS) and serial ATA (SATA) disk drives. Supporting dual architectures allows solutions to be customized for performance, reliability, system expansion flexibility and hard drive capacity. The RAID Controller SRCSAS144E provides flexibility and helps lower total cost of ownership with a standardized server and storage infrastructure. It is designed with four internal SAS ports and four external SAS ports; and the controller utilizes a x4 or wider PCI Express* server board slot.

· Supports SAS devices at speeds up to 300MB/second per port

· Supports the SATA II protocol over SAS transport

· Contains four internal SAS ports and four external SAS ports

· Supports up to 32 physical devices and 64 logical drives

· Supports RAID levels 0, 1, 5, 10, and 50.

· Online capacity expansion

· Online RAID level migration

· Physical drive roaming

· RAID controller migration

· Fast virtual drive initialization

· Hot spare drive configuration, both private and global

· SAS/SATA drive hot plug

· Auto rebuild

· Variable data stripe size configured per virtual drive

· 128 MB of ECC DDR2 SDRAM integrated on the controller

· Read and write cache policy

· SAF-TE, SES2, and SGPIO intelligent enclosure support

· PCI hot plug support

· Background media test (Patrol Read)

· Background data integrity test
