Alcatel-Lucent SAPDUAA DC Power Distribution Panel with Eight Breakers and RALARMAA Alarm Module

CONDITION

New old stock, removed from an equipment enclosure. No original box. Shows some mounting marks, surface scuffs, and storage wear. Please review all photographs for the actual condition and configuration.

IDENTIFICATION

• Manufacturer: Alcatel-Lucent

• Model: SAPDUAA

• Base part number: 3CM02902AA

• Full chassis label: 3CM02902AAAE01

• Nominal voltage: -48VDC / -60VDC

• Assembly label marking: 8 × 100A DC maximum

• Maximum fuse marking: 15A

• Maximum breaker marking: 80A

INSTALLED CONFIGURATION

• Separate A and B distribution sections

• Eight installed breaker switches, four per section

• Circuit chart lists the eight equipped breaker circuits as 50A each

• A3 and B3 positions fitted with blank covers

• Fuse holders installed in AF1, AF2, AF5, AF6 and BF1, BF2, BF5, BF6

• Circuit charts list 5A for fuse positions 1, 2, and 5, and 3A for position 6 on each branch

• RALARMAA alarm module installed

• Alarm module label: 3CM02949AAAD01

• Rear terminal blocks, alarm connector, and ports labeled Eth A and Eth B

• Metal chassis with rack-mount ears

Fuse ratings above are taken from the circuit charts; individual fuse contents have not been independently verified.

A side production-tracking label is dated December 2011.

INCLUDED

One power distribution panel with the installed breakers, fuse holders, alarm module, terminal blocks, and covers shown in the photographs.

No external cables, manuals, or original box included. Functional testing has not been performed by the seller.

Buyer should verify compatibility, ratings, and required components before purchase. Photos show the actual item offered.

Location: A15/S3
