Power supply not included
Supports 12~57V DC power supply
(Maximum current 4 amps)
DC IN port 5.5X2.1mm, inside positive (+) outside negative (-)
52V Power adapter links:
52V1.85A http://www..com/itm/201863649634
48V2A http://www..com/itm/191880113415
If your camera is with word “12V/PoE” as this picture shows, then please select 48V(or 52V)Power Adapter, do not select 12V Power Adapter.
Because "12V/PoE" means it can offer power supply to camera via 12V DC port or 48V PoE Ethernet port:
This is an Passive Power Over Ethernet of 8port 10/100/1000Mbps-T Ethernet switches, including 7 unsolicited PoE Ethernet ports and 1Uplink ports. DC port apply 12~57V power supply adapter(not included), any one of the 7 port can provide output power, each Ethernet port can provide network transmission speeds of up to 10/100/1000Mbps , with Cat5 / 5e / 6 network cable.
Features:
- 8 x 10/100/1000Mbps Auto-negotiation Fast Ethernet RJ-45 ports with 7-Ports PoE function(port 1-port 7)
- Switch Controller Chips Realtek RTL8370N
- Midspan Mode-B Unsolicited Power(4,5+/7,8-)
- Per port Maximum current: 0.84A
- Supports 12~57V DC power supply
- Each port supports auto MDI/MDIX, so there is no need to use cross-over cables.
- Full/half duplex transfer mode for each port.
- Power Input
Supports INPUT 12-57V DC power supply
Power DC port 5.5 x 2.1mm,inside positive (+) outside negative (-) - PoE Power on RJ45
Power +: pin 4 & pin 5 ; Power -: pin 7 & pin 8
DC Output: 12-57V, Per PoE port Max 0.84A, - Product Dimensions 200mm W x 95mm D x 30mm H
- Temperature
Operation Temperature:0 ~40℃ (32 ~104℉)
Storage Temperature: -40 ~70℃(-40 ~158℉) - Humidity
Storage Humidity 5%~90% non-condensing, Operating Humidity 10%~90% non-condensing - Filtering Address Table: 2K entries per device
- Packet Filtering Forwarding Rate
10Mbps Ethernet: 14,880/pps
100Mbps Ethernet: 148,800/pps
1000MBase-T Ethernet: 1,488,000/pps. - MAC address Learning: Automatic update
- Transmission Method: Store – and- Forward
Item Included:
DSLRKIT DIM7P1UKG8pots 7PoEALL GigabitPoE switch x1
(Power supply not included)
