*640x480 VGA resolution USB Camera
*Support Android and Linux system
*Suport YUY and MJPEG format
*high pixel technology for sharp image and accurate color reproduction
*low light performance – ideal for any lighting condition
*Super small outline and thin profile for embedded applications
*High quality lens, true and undistorted color image
*Low power consumption – ideal for portable equipment
* WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above
Specification:
Optional models
ELP-USB30W02M
Sensor
OV7725
Lens size
1/4 inch
Max. Resolution
640X480 VGA
Picture format
YUY2
MJPEG
USB Protocal
USB2.0 HS/FS
USB1.1 FS
Support free driver
USB Video Class(UVC)1.1
Auto exposure AEC
Support
Auto white blance AEB
Support
Frame rate
640(H) x 480 (V) pixels MJPEG 60fps YUY2 30fps
480(H) x 480 (V) pixels MJPEG 30fps YUY2 30fps
450(H) x 450 (V) pixels MJPEG 30fps YUY2 30fps
352(H) x 288 (V) pixels MJPEG 30fps YUY2 30fps
320(H) x 240 (V) pixels MJPEG 30fps YUY2 30fps
288(H) x 288 (V) pixels MJPEG 30fps YUY2 30fps
240(H) x 240 (V) pixels MJPEG 30fps YUY2 30fps
Adjustable parameters
Brightness/Contrast/Color saturation/Definition
Gamma/WB
Support resoluion
640x480 352x288 320x240 160x120
Night vision
optional, can choose IR board
view angle
30-150 degree optional
voltage
DC 5V
current
120mA
work temperature
DEGREES(-20~70)
Size
32x32mm 26x26mm
Support OS
WinXP/Vista/WIN7/WIN8
Linux with UVC
Mac-OS X 10.4.8 or later
Wince with UVC
Android 4.0 or above
Applications:
Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote sitemonitoring, environmental monitoring, etc.
used for all kinds of machine as below:
machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player,
LED display, automatic vending machine, safety box, notebook, video door phone, MID, Tablet external,
evaluator, Medical Equipment, on-the-spot law enforcement, door bell and button system, cat-eye system,
simple security system, teaching system, Interactive system, automobile data recorder. Project video capture,
credit card machine, attendance machine, Voting system, High speed video shooting Device, exam system,
Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance,
endoscope, Medical auxiliary equipment, etc.
